We also stock Bar, Hexagon, Square, Round products in various dimensions and grades. We stock Stainless Steel, Carbon and Alloy specialty steels supplied in the as rolled, annealed and normalized conditions. We offer cut to size and heat treatment through our service center.
User Industries:
Chemicals, Fats, & Fertilizers, Sugar Mills & Distilleries, Cement Industries, Ship
Builders, Paper
Industries, Pumps, Petrochemicals, Oil & Natural Gas Organization in terms of the
specific materials,
Technology, Finance & Personal.
Range:3.17 MM TO 350 MM DIA
Stainless Steel :
ASTM / ASME SA 276 TP 304 , 304L , 309S , 309H, 310S , 316 , 316L , 316 TI , 317 , 321 , 347
, 410 , 420 ,
430 ,431 , 440A ,B & C. , 446 ASTM / ASME SA 479 TP 304 , 304L , 304H, 309S , 309H, 310S
, 310H , 316 ,
316H , 316L , 316 TI , 317 , 321 , 321H , 347 , 347 H , 410, 430 ,431 & 444.
Duplex Steel :
ASTM / ASME SA 276 UNS NO. S 31803 , S 32205 , S 32550 , S 32750 , S 32760.
Range:
1 MM TO 350 MM DIA
Carbon Steel :
ASTM / ASME A 105
Alloy Steel :
ASTM / ASME A 182 GR F 5, F 9 , F 11 , F 12 , F 22 , F 91.
ASTM / ASME A 729 GR B 11 & B 22.
N | C | H | FE | O | AI | V | PA | MO | NI | TI | |
---|---|---|---|---|---|---|---|---|---|---|---|
GR 1 | 0.03 | 0.08 | 0.015 | 0.020 | 0.18 | Â | bal | ||||
GR 2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | bal | |||||
GR 3 | 0.05 | 0.08 | 0.015 | 0.30 | 0.35 | bal | |||||
GR 4 | 0.05 | 0.08 | 0.015 | 0.50 | 0.40 | bal | |||||
GR 5 | 0.05 | 0.08 | 0.015 | 0.40 | 0.20 | 5.5~6.75 | 3.5~4.5 | bal | |||
GR 7 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.12~0.25 | bal | ||||
GR 9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | bal | |||
GR 12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.2~0.4 | 0.6~0.9 | bal |
GRADE | TENSIL STRENGTH(MIN) |
YEILD STRENGTH(MIN) |
ELONGATION(%) | ||
---|---|---|---|---|---|
ksi | MPa | ksi | MPa | ||
1 | 35 | 240 | 20 | 138 | 24 |
2 | 50 | 345 | 40 | 275 | 20 |
3 | 65 | 450 | 55 | 380 | 18 |
4 | 80 | 550 | 70 | 483 | 15 |
5 | 130 | 895 | 120 | 828 | 10 |
6 | 50 | 345 | 40 | 275 | 20 |
7 | 90 | 620 | 70 | 438 | 15 |
8 | 70 | 438 | 50 | 345 | 18 |
DIAMETER | DIAMETER TOLERANCE | LENGTH | TOLERANCE | |||
---|---|---|---|---|---|---|
Forging rod | Extruded Rods | Rolling rod | Ground rod | |||
3.0-4.5 | ±0.05 | ±0.05 | 500-1500 | + 5 | ||
4.5-6.5 | ±0.10 | ±0.10 | 500-1500 | + 5 | ||
6.5-10.0 | ±0.15 | ±0.15 | 400-1500 | + 5 | ||
10-16 | ±0.20 | ±0.20 | 300-1200 | + 5 | ||
16-18 | ±1.0 | ±0.30 | 200-2000 | + 20 | ||
18-25 | ±1.5 | ±1.0 | ±0.40 | 200-2000 | + 20 | |
25-40 | ±2.0 | ±1.5 | ±0.50 | 150-4000 | + 20 | |
40-50 | ±2.5 | ±2.0 | ±0.60 | 100-3000 | + 20 | |
50-65 | ±3.0 | ±2.0 | ±0.80 | 100-1500 | + 20 |
Aluminium Round Bar, Hex Bar, Square Bar Standard |
ASTM, ASME, AMS, ASTMB221M,GB/T3191,JISH4040, ASTM B221, AMS QQ-A-200/9 |
Aluminium Round Bar, Hex Bar, Square Bar Temper |
O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
Aluminium Hex Bar, Square Bar sizes |
Diameter:0.1-600 mm, 10x10 to 200x200, AF 5 mm to AF 100 mm |
Aluminium Round Bar, Hex Bar, Square Bar Length |
1-12 m, Random, Fix & Cut Length or as per clients’ requirement |
Aluminium Round Bar, Hex Bar, Square Bar Finish |
Bright, Polish, Silver, Rough, Powder Colour Coat |
Aluminium Round Bar Hex Bar, Square Bar Surface |
Anodized, Polished, hair line, brush, Matt, Mirror, Mill finished, Bright finish, paper interleaved |
Aluminium Round Bar, Hex Bar, Square Bar Packaging Details |
Exportstandardpackage:bundledwoodenbox,suitforallkindsoftransport orAs per indicated by buyer |
ASTM B221 Aluminium Round Bar Outer packing |
Export standard, wooden pallet, Seaworthy |
Aluminium & Aluminium alloy Round Bar, Hex Bar, Square Bar Grades |
|
Countries, We are Exporting Aluminium Round Bar, Hex Bar, Square Bar |
Brazil, Singapore, South Africa, Indonesia, Ukraine, Korea, Thailand, Vietnam, SaudiArabia, Spain, Canada, USA, Egypt, Iran, India, Kuwait, Dubai, Oman, Kuwait, Peru, Mexico, Iraq, Russia, Malaysia, Iraq, Qatar etc. |
STOKIEST, SUPPLIER, DISTRIBUTORS & EXPORTER OF HINDALCO, NALCO, JINDAL, THYSSENKRUPP, BALCO, VIRGO, MANKASIA, METENERE, INDIA ORIGIN & INTERNATIONAL BRANDS |
EuropeanStandard |
BS (OLD) |
USA (AA) |
GERMANY(DIN) |
ISO |
IS |
Canadian |
EN AW-1050 A |
1E |
1050 |
Al99.5 |
Al99.5 |
19500, 19501 |
1 S |
EN AW-1070 A |
- |
1070 |
Al-99.7 |
Al-99.7 |
19700 |
- |
EN AW-1100 |
IC |
1100 |
Al-99.0 |
Al-99.0 |
19000 |
2 S |
EN AW-2011 |
FC1 |
2011 |
AlCuBiPb |
AlCu6BiPb |
- |
28S |
EN AW-2014 |
HE15 |
2014 |
AlCuSiMn |
AlCu4SiMg |
24345 |
B26S |
EN AW-2024 |
- |
2024 |
AlCuMg2 |
AlCu4Mg1 |
- |
24 S |
EN AW-3003 |
N3 |
3003 |
AlMnCu |
AlMn1Cu |
31000 |
3 S |
EN AW-3103 |
- |
3103 |
- |
AlMn1 |
- |
- |
EN AW-6101A |
E91E |
6101 |
E AlMgSi 0.5 |
E AlMgSi(A) |
63401 |
D50S |
EN AW-6005 |
- |
6005 |
AlMgSi0.7 |
AlSiMg |
62400 |
C51S |
EN AW-6351 |
HE30 |
6351 |
AlMgSi1 |
AlSiMg0.5Mn |
64430 |
B51S |
EN AW-6060 |
- |
6060 |
AlMgSi 0.5 |
AlMgSi |
- |
- |
EN AW-6061 |
HE20 |
6061 |
AlMgSiCu |
AlMg1SiCu |
65032 |
65S |
EN AW-6063 |
HE9 |
6063 |
AlMgSi0.5 |
AlMg0.7Si |
63400 |
50S |
EN AW-6082 |
HE30 |
6351 |
AlMgSi1 |
AlSi1MgMn |
64430 |
B51S |
